Description

The Kino Flo FreeStyle Mini LED DMX System, Univ is a compact and versatile lighting solution designed for professional film, television, and photography applications. This system features the FreeStyle Mini LED fixture, which offers precise control over light intensity, color temperature, and effects via DMX.  With its universal power input, it is compatible with various power sources, making it ideal for both studio and on-location shoots.

System Includes: FreeStyle Mini LED Fixture, Louver 90°, Freestyle 120 LED DMX Controller, KinoGrip 41K w/Baby Receiver Short, 15ft Head Extension,

FreeStyle Mini Features

• Color Rendering TLCI >96, CRI >96, TM-30-18 Rf=95, Rg=103
• Kelvin presets
• Dial-in color temperature control between 2500K-9900K
• Green/Magenta Control
• Hue angle and Saturation adjustments
• RGB control
• CIE xy
• FX Control
• Camera Profiles LUTs
• Color Space
• Works with Apps with predetermined RGB presets or color wheels
• Can use preset buttons to store custom Kelvin settings
• Light levels do not change when selecting Kelvin settings
• No color shift while dimming
• Universal input 100VAC-240VAC or 24VDC
• Energy efficient, draws 0.83A, 120VAC and 4.2A, 24VDC
• Flicker-free, quiet operation
• Full range onboard and DMX dimming
• DMX wireless link (Lumen Radio®)
• DMX Auto Terminate
• LED Controller can power two FreeStyle Mini Fixtures – (Both at same settings)
• Dimensions : 15 x 3 x 7.5″ (38 x 8 x 19cm)
• Weight: 3.5 lb (2kg)

FreeStyle Mini Design

• KinoGrip Center Mount
• Lightweight, compact, slim profile
• Mounts to stand, light enough to be hand-held

FreeStyle Mini Modular Design

The FreeStyle Mini LED Fixture is comprised of a an LED panel and Louver.  The Louver is held in place with Velcro fasteners.  The fixture has a twist-on mating plate to accept a twist-on mount and has molded corners for additional rigging options.  The compact lightweight fixture can also be hand-held. The FreeStyle Mini LED DMX Controller firmware is updatable from a PC using the Mini B USB data port.
