Vortex2 Soft

*Available for Demo - Please Contact sales@llsr.com for more info

Features

A premium high-powered 1’x0.5′ LED fixture designed for heavy use in all conditions.

Offers 2 pixel zones for precise, dimmable lighting effects with consistent colour accuracy and no drift.

Front latch system for quick diffuser and accessory changes.

IP65 water-resistant with a built-in power supply and all the advanced connectivity for professional use.

Optimised for a range of applications with RRGBBW, a wide CCT range, and high speed modes for shooting up to 5000fps.

Sync Input for triggering and syncing to camera shutter.

Multiple control options, including an etherCON port, pass-through 5-pin XLR DMX, LumenRadio CRMX, and BLE.

48V DC input using industry-standard 3-pin XLR.

Specs:

Head Weight

5.5 kg / 12.13 lb (Excluding yoke)

6.97 kg / 15.37 lb (Including yoke)

Dimensions

390 x 207.6 x 183.6 mm / 15.35 x 8.17 x 7.23 in. (Excluding Yoke)

537.7 x 433.2 x 176.6 mm / 21.17 x 17.06 x 6.95 in. (Including Yoke)

Protection Class

IP65

Open Face Beam Angle

110°

Maximum Ambient Temperature

40°C / 104°F

Output

High-efficiency native soft light with 160W pass-through AC power capabilities.

A 110° beam produces 662 lx @ 3 m (5600K, Open Face).
