Blackmagic 2110 IP UpDownCross 12G Converter
Out of Stock – Please email us for an accurate lead time.
Description
Blackmagic 2110 IP UpDownCross 12G is a professional standards converter that lets you convert between any equipment with SMPTE-2110 IP video, 12G‑SDI and HDMI video connections. You get the highest quality conversion between all SD, HD or Ultra HD video standards plus reference input for built in re-sync and redundant power supplies. The USB port on the front panel even works as an HD webcam.
Connections
SDI Inputs
1
SDI Loop Outputs
1
SDI Outputs
2
SDI Rates
SD, 1.5G, 3G, 6G and 12G
HDMI 2.0 Video Outputs
1
SMPTE 2110 Input / Output
1 x 10G Ethernet
SMPTE ST 2110 IP Audio Inputs / Outputs
16 channels embedded input and output audio on ST‑2110 IP video via 10G Ethernet.
SDI Audio Inputs
16 channels embedded audio.
SDI Audio Outputs
16 channels embedded audio.
HDMI Audio Inputs
8 channels embedded audio.
HDMI Audio Outputs
8 channels embedded audio.
Analog Audio Outputs
1 x 6.35 mm headphone jack.
Webcam Outputs
1 x USB-C up to 1080p60
Reference In
1
Reference Output
1
Ethernet
Ethernet supports 10/100/1000/10G BASE-T for SMPTE 2110 IP video in and out, configuration and software updates.
Computer Interface
USB-C for webcam out, updates and configuration.
