Blackmagic URSA Cine 17K 65 Digital Film Camera Body

Description

Blackmagic URSA Cine 17K 65 is a revolution in digital film with an extremely large format 17520 x 8040 65mm RGBW sensor with larger photo-sites for 16 stops of dynamic range. The URSA Cine 17K 65 Body model is ideal when you have existing camera accessories that you want to use to create your own camera rig. It excludes top handle, baseplate, power supply, battery plate and LPL lens mount. It does come with an interchangeable PL lens mount, a dedicated assist station with a second 5″ HDR LCD touchscreen and industry standard Lemo and Fischer connections. Blackmagic URSA Cine 17K 65 Body also includes an 8TB media module, high speed 10G Ethernet and WiFi for fast media upload and syncing to Blackmagic Cloud.

Camera Features

Effective Sensor Size

50.81 mm x 23.32 mm (65mm Format)

Pixel Pitch

2.9 microns

Lens Mount

PL mount. Interchangeable with optional URSA Cine Mounts, LPL, EF and HC.

Lens Control

Lens data from compatible PL or LPL lenses and control of some PL lenses. Lens control of compatible EF lenses.

Dynamic Range

16 Stops

Shooting Formats

17,520 x 8040 (17K 2.2:1 open gate)

16,128 x 8040 (17K 2:1)

15,360 x 8040 (17K 17:9)

14,304 x 8040 (17K 16:9)

17,520 x 7296 (17K 2.4:1)

12,288 x 8040 (12K 3:2)

12,288 x 6912 (12K 16:9)

12,288 x 6480 (12K 17:9)

12,288 x 5112 (12K 2.4:1)

9648 x 8040 (12K 6:5)

11,680 x 5360 (8K 2.2:1 open gate)

10,752 x 5360 (8K 2:1 full height)

8192 x 5360 (8K 3:2)

8192 x 4608 (8K 16:9)

8192 x 4320 (8K 17:9)

8192 x 3408 (8K 2.4:1)

5840 x 2680 (4K 2.2:1 open gate)

5376 x 2680 (4K 2:1 full height)

4096 x 2680 (4K 3:2)

4096 x 2304 (4K 16:9)

4096 x 2160 (4K 17:9)

4096 x 1704 (4K 2.4:1)

Frame Rates

Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported. Maximum sensor frame rate dependent on resolution selected.
